Name: Drywall Omega Profile Light Gauge Steel Roll Forming Machine For Galvanized Plate
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Pejantan dan lacak
Price: 40,500.00 USD
Availability: InStock

Rumah > Produk > Mesin Membentuk Roll Stud And Track >

Drywall Omega Profile Light Gauge Steel Roll Forming Machine For Galvanized Plate

drywall light gauge steel roll forming machine

galvanized light gauge steel roll forming machine

drywall omega profile roll forming machine

Tempat asal:

China daratan

Nama merek:

CANGZHOU FMS

Sertifikasi:

ISO CE

Nomor model:

Pejantan dan lacak

Hubungi Kami

Minta Penawaran Harga

Detail Produk

Nama Produk:

Gunakan untuk Mesin Roll Forming Baja Pengukur Cahaya Profil Omega Drywall

Dimensi (P*L*T):

6500*1300*1100

Jenis ubin:

Baja galvanis

Menggunakan:

Sel dinding kering

Kapasitas Produksi:

8-12 m/mnt

Berat:

3000kg

Voltase:

380V 50Hz 3 fase

Sistem Pengendalian:

PCL

Menyoroti:

drywall light gauge steel roll forming machine

galvanized light gauge steel roll forming machine

drywall omega profile roll forming machine

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Harga

negotiable

Kemasan rincian

FLC 20'

Waktu pengiriman

30 hari kerja

Syarat-syarat pembayaran

L/c, t/t, d/a, d/p

Menyediakan kemampuan

20 set per bulan

Produk terkait

Video

Omega Profile Light Keel Steel Framing Top Hat Channel Roll Forming Machine

Dapatkan Harga Terbaik

C89 Lgs Light Gauge Steel Roll Forming Machine For Villa House

Dapatkan Harga Terbaik

Roller Fixer Guide Column CU stud for Long-lasting Roofing

Dapatkan Harga Terbaik

Guide Column Roller Fixer Stud And Track Roll Forming Machine with 7.5KW Hydraulic Station Power and Plc S7-200 Control

Dapatkan Harga Terbaik

Hubungi Kami

86-317-2016816

Hubungi Sekarang

Deskripsi produk

Use for Drywall Omega Profile Light Gauge Steel roll Forming Machine

Omega profile roll forming machine popular sell in many countries. Product thickness common between 0.3-1.2 mm, we had export lots of such machine to Iraq, Egypt, UAE, Chile, Zambia, etc. As a result of the stable operation of the machine, the customers are well satisfied with the production speed

Specification

1	Plate Material	Galvanized plate
	Thickness	0.3-1.2mm
	Wall thickness of the main forming machine	25mm steel plate
2	Reducer	3kw which works stably and no noise.
2	Rollers	11 steps
3	Diameter of active shaft	48mm, 45# steel
	Hydraulic pump power	3KW
	Woking Speed	8-12m/min
	Material of shaft	45# steel with chrome 0.05mm
4	Operate	Automatic Hydraulic / Electric type
4	Blade material	Cr12MOV
5	Pump motor for cutter	4KW
	Main Motor	5.5KW
	Voltage	380V 50Hz 3 Phase
6	Electric Box	PLC control system , Inverter
6	Language	English / Chinese

Application
To form rigid suspended ceiling framework, Omega channel clips are used with U-channel, hanger wire, and Omega channel clips on masonry walls and ceiling assemblies.

Advantage

The material of the light steel keel itself is relatively light. The gravity of the product made by this material is relatively light, so it is more suitable for it on the ceiling, and its fire resistance is also very high. Fire resistance is high.
The construction efficiency of light steel keel is also relatively high. The construction method it uses is relatively simple, so the efficiency is very high, so its construction time is relatively short, and its structure is very safe, that is, it is its structure, that is, it is its structure, that is, it is its structure. The solidity is very high, so it is relatively high in terms of safety

Drywall Omega Profile Light Gauge Steel Roll Forming Machine For Galvanized Plate 0
