Name: Steel Metal Heavy Thickness Coil Leveling 1.5mm 1200mm PPGI Cut To Length
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Potong memanjang
Price: 26,500.00 USD
Availability: InStock

Rumah > Produk > Potong Memanjang Dan Menggorok Garis >

Steel Metal Heavy Thickness Coil Leveling 1.5mm 1200mm PPGI Cut To Length

steel metal coil leveling machine

heavy thickness PPGI cut to length

1200mm width coil leveling line

Tempat asal:

CINA

Nama merek:

CANGZHOU FMS

Sertifikasi:

ISO, CE

Nomor model:

Potong memanjang

Hubungi Kami

Minta Penawaran Harga

Steel Metal Heavy Thickness Coil Leveling 1.5mm 1200mm PPGI Cut To Length

Detail Produk

Nama Produk:

Baja Logam Ketebalan Berat Coil Leveling 1.5mm 1200mm PPGI Dipotong Panjang

Bahan pemotongan:

CR12MOV

Ketebalan material:

0.8mm -1.5mm

Kecepatan kerja:

8m/menit - 20m/menit

Berat kumparan:

5 ton / 7 ton / 10 ton/15ton

Berat mesin:

13.000 kg

Toleransi memotong:

±2 mm

Menyoroti:

steel metal coil leveling machine

heavy thickness PPGI cut to length

1200mm width coil leveling line

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Tetapkan Lini Produksi

Harga

negotiable

Kemasan rincian

2 buah FLC 40'

Waktu pengiriman

60 hari kerja

Syarat-syarat pembayaran

L/c, d/a, d/p, t/t

Menyediakan kemampuan

5 set per 60 hari

Produk terkait

Video

steel coile 40m/min High Speed Slitting Line Machine With Hydraulic Uncoiler And Recoiler

Dapatkan Harga Terbaik

Video

40m/min High Speed Slitter Slitting Line Machine With Hydraulic Uncoiler And Recoiler

Dapatkan Harga Terbaik

Video

380v 50hz High Speed Steel Coil Slitter Slitting Producttion Line Machine With Hydraulic Uncoiler And Recoiler

Dapatkan Harga Terbaik

Video

High Speed Slitter Slitting Line Machine With Hydraulic Uncoiler And Recoiler

Dapatkan Harga Terbaik

Hubungi Kami

86-317-2016816

Hubungi Sekarang

Deskripsi produk

Steel Metal Heavy Thickness Coil Leveling 1.5mm 1200mm PPGI Cut To Length

Product Description

Multi-Function Metal Coil Leveling Slitting And Cut To Length

Steel Coil Cutting-to-Length Lines are integrated systems of machinery designed to process large, master coils of steel into flat sheets. This process is fundamental in metal manufacturing, transforming coiled raw material into ready-to-use flat products for various industries.

These highly automated lines handle the three primary functions: uncoiling, levelling (straightening), and cutting.

Specifications

No.	Item	Description
Main Specification
1	Raw Material	Galvanized, Aluminum, Color steel, Hardness 235MPa - 485MPa
2	Raw Material Thickness	0.2 mm - 3.0 mm
3	Raw Material Width	600 mm - 1600 mm
4	Tape Inner Diameter	φ 480 mm - φ 530 mm
5	Tape Outer Diameter	φ 1600 mm
6	Coil Weight	5 tons - 10 tons
7	Brand	FMS
8	The Highest Slitting Line Speed	8 m/min - 30 m/min
9	Minimum Cutting Line Width	35 mm
10	Cutting Width Precision	± 0.01 - ± 0.05 mm
11	Rated Operational Voltage	380 V, 3 Phase, 60 Hz
12	Total Weight	14000 KG
13	Working Space (L*W)	20000 mm * 6000 mm
Decoiler Machine Specification
1	Tape Outer Diameter	Max φ 1600 mm
2	Tape Width	600 mm - 1600 mm
3	Tape Inner Diameter	φ 480 mm - φ 530 mm
4	Coil Weight	5 /7/10 tons
5	Max Working Speed	8 m/min - 30 m/min
6	Tape Tight Range	φ 480 mm - φ 530 mm
7	Shaft Diameter	φ180 mm
8	Roller Effective Length	1600 mm
9	Drive Motor Power	5 KW
10	Loading Car Diameter	φ 700 mm - φ 1500 mm
11	Loading Car Weight	5 /7/ 10 tons
12	Car Speed	About 4 m/min

Application

Used to cut the big coils into different width coils. The thickness can be 0.3-3mm GI PPGI, with a working speed that can reach 40 meters per minute. Maximum width of steel coils can be 1250mm.

Advantage

Cangzhou Famous Cold Roll Forming Machinery is a professional manufacturer and exporter that specializes in the design, development and production of cold roll forming machines.

Located in Botou City, all products comply with international quality standards and are greatly appreciated in various markets throughout the world, including Asia, Africa, Europe, South America, and Australia.
