0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making

0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making

cold roll forming machine ppgi

purlin roll forming machine ppgi

0.8mm cold roll forming machine

Tempat asal:

China daratan

Nama merek:

CANGZHOU FMS

Sertifikasi:

ISO CE

Nomor model:

Saluran Pintu Rana

Hubungi Kami
Minta Penawaran Harga
0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making
0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making 0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making 0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making 0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making 0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making
Detail Produk
Nama Produk:
Mesin Pembuat Pintu Panel Mesin Rolling Shutter Slats Roller Forming
Kecepatan:
15m/mnt
Voltase:
380V 50Hz 3 Fase Atau Pelangganisasi
Bahan pemotongan:
45# Baja Tempa Disepuh dengan Krom Keras
Komponen inti:
Motor, Bantalan, Roda Gigi, Pompa, PLC
Kekuatan:
3kw/5.5kw
Sistem Pengendalian:
PLC
Berat:
1500 kg
Menyoroti:

cold roll forming machine ppgi

,

purlin roll forming machine ppgi

,

0.8mm cold roll forming machine

Syarat Pembayaran & Pengiriman
Kuantitas min Order
1 Set
Harga
negotiable
Kemasan rincian
FLC 20'
Waktu pengiriman
30 hari kerja
Syarat-syarat pembayaran
L/c, t/t, d/a, d/p
Menyediakan kemampuan
20 set per bulan
Produk terkait
Harga bagus Metal Chain Driving Shutter Door Roll Forming Machine Speed 20-30m/Min on line Video

Metal Chain Driving Shutter Door Roll Forming Machine Speed 20-30m/Min

Dapatkan Harga Terbaik
Harga bagus Customized High Speed PU Door Roller Shutter Roll Forming Machine on line Video

Customized High Speed PU Door Roller Shutter Roll Forming Machine

Dapatkan Harga Terbaik
Harga bagus 3T Shutter Door Roll Forming Machine For 0.8-1.2mm Thickness And 6.5m*0.95m*1.2m Size on line Video

3T Shutter Door Roll Forming Machine For 0.8-1.2mm Thickness And 6.5m*0.95m*1.2m Size

Dapatkan Harga Terbaik
Harga bagus 45 Steel Roller Material Shutter Door Roll Forming Machine with 7.5KW PLC Control System on line Video

45 Steel Roller Material Shutter Door Roll Forming Machine with 7.5KW PLC Control System

Dapatkan Harga Terbaik
Hubungi Kami
Hubungi Sekarang
Deskripsi produk

Metal Frame C Purlin Channel Cold Rolling Making Machine


Roller shutter door channel roll forming machine is used for producing shutter door side channel ,which will be used together with guide rail and bottom rail .the Raw material for shutter door machine is galvanized coil or pre painted steel coil ,coil thickness is 0.8-1.2mm ,for this type machine have been sent to many countries such as Singapore,Oman ,Pakistan ,Dominica etc
Slat shutter door U channel machine is the most common style ,it is used fro making flat shutter door panels ,simple but strong and cost effective ,many custoners choose this style



Specification



No
Item
Specification

Material
Raw material
GI or PPGI
Material thickness
0.8-1.2MM






Machine body
Roller material
Cr12 quenched
Shaft material
High grade 45# steel with Cr12 quenched
Shaft diameter
50mm
Roller stations
15
Middle plate thickness
16mm
Machine size
5*0.8*1.2m
Productivity
8-15m/min

Cutter
Material
GCR12
Method
Hydraulic cutting



Power
Driving way

Chain 1.2 inch
Motor
4KW
Hydraulic oil pump
3KW
Voltage
380V,50HZ ,3 phase or customized as your need




0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making 0


Guarantee

In correct operation and maintenance, the machines are 12 months quality guarantee from time of loading, life guarantee repair; within quality guarantee period, except for failures caused by human error, spare parts will be provided freely; after the quality guarantee period, only charge the cost of the spare parts. Free technical supporting and maintenance consulting in lifetime.


Payment terms

35 % in advance as down payment
65 % is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port
The Delivery Time: 30 days after the down payment is received.
