Name: Automatic Floor Deck Roll Forming Machine 20 - 25m/Min
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: dek lantai
Price: 26,500.00 USD
Availability: InStock

Rumah > Produk > Mesin Membentuk Rol Dek Lantai >

Automatic Floor Deck Roll Forming Machine 20 - 25m/Min

floor decking machine 20m/min

Auto Floor Deck Roll Forming Machine

floor deck forming machine 20m/min

Tempat asal:

China daratan

Nama merek:

FMS

Sertifikasi:

ISO CE

Nomor model:

dek lantai

Hubungi Kami

Minta Penawaran Harga

Detail Produk

Nama Produk:

Mesin Roll Forming Dek Lantai Otomatis Berkualitas Tinggi Mesin Pembuat Lantai

Dimensi (P*L*T):

9000*1700*1500Mm

Lebar efektif:

1000mm

Jenis kontrol:

Sistem PLC

Voltase:

380V 50Hz 3Phase

produktivitas:

20-25m/mnt

Ketipisan bergulir:

0,7-2,0mm

Berat:

6000 kg

Menyoroti:

floor decking machine 20m/min

Auto Floor Deck Roll Forming Machine

floor deck forming machine 20m/min

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Harga

negotiable

Kemasan rincian

FLC 40'

Waktu pengiriman

30 hari kerja

Syarat-syarat pembayaran

L/c, t/t, d/a, d/p

Menyediakan kemampuan

20 set per bulan

Produk terkait

Video

Cellular Composite Roofing Sheet Making Machine 3.0" Width 0.8-2.0MM Thickness

Dapatkan Harga Terbaik

Video

13 Rows Roof Tile Roll Forming Machine For Tipo Teja Americana Normal Tile

Dapatkan Harga Terbaik

Video

Decking Flooring Board 1.2mm Floor Tile Making Machine

Dapatkan Harga Terbaik

Video

45 Steel Deck Roll Forming Machine Cold ±2mm Cutting Tolerance Excellent Performance

Dapatkan Harga Terbaik

Hubungi Kami

Hubungi Sekarang

Deskripsi produk

High Quality Automatic Floor Deck Roll Forming Machine Floor Making Machine

High Quality Automatic Floor Deck Roll Forming Machine Floor Making Machine Price

We can provide floor deck roll forming machine for building a big construction, we provide accuracy rollers to satisfy reinforced rib of floor deck, satisfy the customer’s requirement of hardness of floor deck, solve the problem of loading capacity of each floor.We equip 400 I Beam as the main structure of machine base, large loading capacity and stable structure, solve the problem of producing if workshop place isn’t flat.

Working Flow:

Decoiler-------Feeding-------Roll forming-------Cutting------Finished product

Specification

After-sales Service Provided	Engineers available to service machinery overseas
raw material	PPGI PPGL GI GL
warranty	1 years
plc	mitsubishi/delixi/siemens
cutting blade material	cr12 with quenched treatment
Roller materials	45# Forging Steel with Chromium Plate
Main Shaft Material	45# steel with finish turning
Machine Main Frame	400 I Beam
Hydraulic pressure	18-20Mpa

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
