Name: 4m 6m Metal Iron Sheet Cutting Hydraulic Bending Machine Automatic
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Pembengkokan
Price: 40,000.20 USD
Availability: InStock

Rumah > Produk > mesin bending hidrolik >

4m 6m Metal Iron Sheet Cutting Hydraulic Bending Machine Automatic

6m automatic hydraulic pipe bending machine

Hydraulic Bending Machine Automatic

4m automatic hydraulic pipe bending machine

Tempat asal:

CINA

Nama merek:

FMS

Sertifikasi:

CE,ISO

Nomor model:

Pembengkokan

Hubungi Kami

Minta Penawaran Harga

Detail Produk

Nama Produk:

Mesin Bending Hidrolik Pemotong Lembaran Besi Logam 4m 6m Otomatis

Bahan / Logam diproses:

Baja Karbon, aluminium. logam

Produktivitas tinggi:

Produktivitas tinggi

Kekuatan:

Hidrolik

Tenaga Motorik:

4KW

Ketebalan Lipat:

seperti yang diminta

Lonjakan stasiun pompa:

1MP-40MP

Tenaga listrik stasiun pompa:

4KW

Menyoroti:

6m automatic hydraulic pipe bending machine

Hydraulic Bending Machine Automatic

4m automatic hydraulic pipe bending machine

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Harga

negotiable

Kemasan rincian

Mesin utama telanjang, kotak kontrol komputer dikemas dengan plastik.

Waktu pengiriman

30 hari

Syarat-syarat pembayaran

T/T, Serikat Barat, L/C,

Menyediakan kemampuan

30 set per bulan

Produk terkait

Video

Acrylic Cnc Iron Plc Hydraulic Bending Machine 12m/Min

Dapatkan Harga Terbaik

Video

Automatic Roll Forming 380v Hydraulic Steel Bending Machine 6 Meter

Dapatkan Harga Terbaik

Video

Cnc Sheet Metal 1600mm Hydraulic Press Brake Bending Machine

Dapatkan Harga Terbaik

Video

2m / 4m / 6m Hydraulic Steel Bending Machine For Roofing Sheet

Dapatkan Harga Terbaik

Hubungi Kami

86-317-2016816

Hubungi Sekarang

Deskripsi produk

4m 6m Metal Iron Sheet Cutting Hydraulic Bending Machine Automatic

4m 6m Metal Iron Sheet Cutting Hydraulic Bending Machine Automatic Usage:

1. First, connect the power supply, open the key switch on the control panel, and then press the oil pump to start, so that you can hear the sound of the oil pump. (The machine does not act at this time) 2, travel adjustment, the use of the bending machine must pay attention to adjust the travel, must be tested before bending. Bending machine die down to the bottom must ensure that there is a plate thickness clearance. Otherwise, it will cause damage to the mold and machine. The adjustment of the stroke is also electric quick adjustment and manual stomach adjustment. 3, bending groove selection, generally choose the plate thickness of 8 times the width of the notch. Such as bending 4mm sheet material, need to choose about 32 notch. 4, the rear stopper adjustment is generally electric rapid adjustment and manual fine tuning, the method is the same as the plate shearing machine. 5, step down the foot switch to start bending, bending machine and shearing machine is different, can be released at any time, loosen the foot bending machine will stop, continue to step down.

Equipment Detailed Parameters:

No.	Main parameter
1	Suitable to process	color steel plate, steel plate, galvanized sheet and so an.
2	Raw material thickness	0.3 ~ 1 mm
3	Bending Angle	30° 45° 60° 90° 130°
4	Motor power	3KW
5	length	as per requested
6	Material	prepaitned steel
7	Warranty of core components	1 Year
8	Voltage	380V 50Hz 3phasesas per requested
9	Core Components	Motor, PLC
10	length	6m

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for 12 months after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% TT in advance

60% TT before the shipment and after inspection

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 20 days after the down payment is received.
