Name: Color Steel Corrugated Wave Shape Roofing Steel Sheet Making Machine 8-15m/Min
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Bergelombang
Price: 16,000.00 USD
Availability: InStock

Rumah > Produk > Mesin Roll Forming Genteng >

Color Steel Corrugated Wave Shape Roofing Steel Sheet Making Machine 8-15m/Min

Hydraulic corrugated steel sheet making machine

15m/Min steel sheet making machine

8m/Min steel sheet making machine

Tempat asal:

CINA

Nama merek:

fms

Sertifikasi:

CE,ISO

Nomor model:

Bergelombang

Hubungi Kami

Minta Penawaran Harga

Color Steel Corrugated Wave Shape Roofing Steel Sheet Making Machine 8-15m/Min

Detail Produk

Nama Produk:

Mesin Roll Forming Bergelombang Baja Warna Mesin Pembuat Atap Lembaran Besi Bergelombang

Jenis ubin:

Baja galvanis atau PPGI

Kapasitas Produksi:

8-20 m/menit

Berat:

4500 kg

Bahan roller:

380V 3 Fase 50HZ

Lebar makan:

0,4-0,8 mm

Lebar koil sebelum digulung:

1200mm, 1220mm, 1250mm

Ukuran penampilan:

6*1,5*1,3 m

Bahan roller:

Baja 45# dengan krom 0,05mm

Pemotongan:

Pemotongan hidrolik

Menyoroti:

Hydraulic corrugated steel sheet making machine

15m/Min steel sheet making machine

8m/Min steel sheet making machine

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Harga

negotiable

Kemasan rincian

Mesin utama telanjang, kotak kontrol komputer dikemas dengan plastik.

Waktu pengiriman

30 hari

Syarat-syarat pembayaran

T/T, Western Union

Menyediakan kemampuan

30 set per bulan

Produk terkait

6m Automatic Stacker for Roof Sheet Roll Forming Machine

Dapatkan Harga Terbaik

Video

the factory price for 0.3-0.8mm thickness Glazed Roof sheet forming machine

Dapatkan Harga Terbaik

Video

2025 New Design for Glazed Roof Tile Roof Sheet Roll Forming Machine With 18 Rows

Dapatkan Harga Terbaik

Video

4meter/Min Glazed Tile Roll Forming Machine With 18 Rows

Dapatkan Harga Terbaik

Hubungi Kami

86-317-2016816

Hubungi Sekarang

Deskripsi produk

8-15m/Min Color Steel Corrugated Wave Shape Roofing Steel Sheet Making Machine

The color plate produced has a flat and beautiful appearance, no any scratch on surface of sheets . It is widely used in industrial and civil buildings, such as factories, warehouses, gymnasiums, exhibition halls, theaters, etc. House surfaces and walls.

Specification

NO.	Item	Specification
Material	Raw material	Galvanized steel or PPGI
Material	Thickness	0.4-0.8 mm
Machine	Roller station	12 or depend on customer' drawing
	Shaft diameter	70 mm
	Solid shaft material	High grade 45# steel with Cr12 mov coated, quenching & tempering & treatment
	Roller material hardness 30-40 HRC	Cr12
	Machine size	About 61.51.3 m
	Machine weight	About 5 tons
	Machine color	As customer need
	Working speed	8-20 m/min
Cutter	Hardness	50-65 HRC
	Cutting tolerance	± 1mm
	Material	Cr12
	Operate	Hydraulic cutting
Power	Driving way	Chain 1 inch
	Main motor	5.5 KW
	Pump motor for cutter	3 KW
	Voltage	380V/50HZ, 3P or Customized as customer' request
Control system	PLC brand	Delta made in Taiwan
	Screen	Touchable screen
	Language	Chinese and English or add customer need language
Decoiler	Operation	Manual
	Weight capacity	5 Tons
	Price	Free as gift
Receive table	Operation	Manual
Receive table	Length	3 m

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for 12 months after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% TT in advance

60% TT before the shipment and after inspection

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 20 days after the down payment is received.
