Auto Double Deck Sheet Metal Forming Machine 8 - 15m/Min

Auto Double Deck Sheet Metal Forming Machine 8 - 15m/Min

8m/min Sheet Metal Forming Machine

Double Layer Panel Roll Forming Machine

Double Deck Sheet Metal Forming Machine

Tempat asal:

CINA

Nama merek:

FMS

Sertifikasi:

CE,ISO

Nomor model:

Lapisan ganda

Hubungi Kami
Minta Penawaran Harga
Auto Double Deck Sheet Metal Forming Machine 8 - 15m/Min
Auto Double Deck Sheet Metal Forming Machine 8 - 15m/Min Auto Double Deck Sheet Metal Forming Machine 8 - 15m/Min
Detail Produk
Deskripsi produk:
Mesin Roll Forming Panel Lapisan Ganda Otomatis Mesin Pembentuk Logam Lembaran Dek Ganda
Bahan:
Baja, Baja Warna, Aluminium
Kapasitas Produksi:
8-15m/mnt
Sistem Pengendalian:
PLC
Ketebalan material:
0.3-0.8mm
Voltase:
380V 60 HZ atau Disesuaikan
Diameter poros:
65mm
Cutting Blade Material:
Cr 12 baja bermutu tinggi
Berat:
6.5T
Daya Motor Utama:
4KW
Menyoroti:

8m/min Sheet Metal Forming Machine

,

Double Layer Panel Roll Forming Machine

,

Double Deck Sheet Metal Forming Machine

Syarat Pembayaran & Pengiriman
Kuantitas min Order
1 Set
Harga
negotiable
Kemasan rincian
Mesin utama telanjang, kotak kontrol komputer dikemas dengan plastik.
Waktu pengiriman
30 hari
Syarat-syarat pembayaran
T/T, Western Union
Menyediakan kemampuan
35 set per bulan
Produk terkait
Harga bagus 2025 factory best price Trapezoidal and glazed Double Layer Roof sheet Forming Machine on line Video

2025 factory best price Trapezoidal and glazed Double Layer Roof sheet Forming Machine

Dapatkan Harga Terbaik
Harga bagus 2025 factory price Trapezoidal and glazed Double Layer Roof sheetForming Machine on line Video

2025 factory price Trapezoidal and glazed Double Layer Roof sheetForming Machine

Dapatkan Harga Terbaik
Harga bagus 2025 factory priceDouble Layer Roof sheetForming Machine on line Video

2025 factory priceDouble Layer Roof sheetForming Machine

Dapatkan Harga Terbaik
Harga bagus 2025 factory price Trapezoidal and glazed Double Layer Roof sheet roofing tile Roll Forming Machine on line Video

2025 factory price Trapezoidal and glazed Double Layer Roof sheet roofing tile Roll Forming Machine

Dapatkan Harga Terbaik
Hubungi Kami
86-317-2016816
Hubungi Sekarang
Deskripsi produk

 Auto Double Layer Panel Roll Forming Machine Double Deck Sheet Metal Forming Machine

   This Auto Double Layer Panel Roll Forming Machine Double Deck Sheet Metal Forming Machine. Compare to two seperate roll forming machine,this kind of double layer forming machine saves the space and cost. But the two layers share same transmission system, control system and cutting system. It means the two shapes of sheets can not working at same time. So the working productivity is less
than two sperate machines.



Detailed Parameters:



No.
Type
specification
1
Row Material
Type
Color steel plate, galvanized plate, aluminum plate
Feeding width
According to client's requirement
Thickness
0.3-0.8mm




Effiect width
1000mm
2
Main body
Forming roller station
Up layer: 12 stations ; Down layer: 18 stations
Diameter of shaft
70mm
Shaft material
High grade 45# steel ( heat treatment, plated ome on surface)
Roller material
High grade 45# steel
frame
300mm H Steel
Frame thickenss
18mm
Working speed
8-12 m/min
Size (L*W*H)
About 8600*1550*1510mm
Weight
About 6.5 tons
3
Power
Motor power
4KW
Hydraulic power
4KW
Voltage
380V 50Hz 3phases or Customerization
4
PLC Contro System
Language
English and Chinese
Brand Of PLC
Delta brand (Touch Screen )
Operation
Manual and Automatic (Two Type)
Transducer
Delta brand
5
Cutting Device
Cutting Type
Hydraulic Cutting
Blade of Cutting
Cr12 , quenching treatment
Cutting Tolerance
+ -1mm



Guarantee



1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation



Payment terms



40% in advance as down payment

60% is paid before the shipment is processed



Delivery



FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
