Name: 915 Floor Deck Roll Forming Machine Full Automatically Hydraulic System
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: dek lantai
Price: 26,500.00 USD
Availability: InStock

Rumah > Produk > Mesin Membentuk Rol Dek Lantai >

915 Floor Deck Roll Forming Machine Full Automatically Hydraulic System

Hydraulic System Floor Deck Roll Forming Machine

Hydraulic System deck roll former

Floor Deck Forming Machine Full Automatically

Tempat asal:

China daratan

Nama merek:

FMS

Sertifikasi:

ISO CE

Nomor model:

dek lantai

Hubungi Kami

Minta Penawaran Harga

Detail Produk

Nama Produk:

Penjualan Panas Mesin Roll Forming Dek Lantai 915 Sistem Hidraulik Otomatis Penuh

Bahan Pemotong:

Baja cetakan CR12

Poros:

Baja Padat 82mm

Lebar makan:

1220mm (Dapat dirancang sesuai permintaan pembeli)

Berat:

sekitar 10t

Voltase:

380V 50Hz 3Phase

Kapasitas Produksi:

25m/menit.

Thinckness:

0,8-1,2mm

Dimensi (P*L*T):

12000*1500*1500mm

Motor utama:

11KW * 2

Menyoroti:

Hydraulic System Floor Deck Roll Forming Machine

Hydraulic System deck roll former

Floor Deck Forming Machine Full Automatically

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Harga

negotiable

Kemasan rincian

FLC 40'

Waktu pengiriman

30 hari kerja

Syarat-syarat pembayaran

L/c, t/t, d/a, d/p

Menyediakan kemampuan

20 set per bulan

Produk terkait

Video

Cellular Composite Roofing Sheet Making Machine 3.0" Width 0.8-2.0MM Thickness

Dapatkan Harga Terbaik

Video

13 Rows Roof Tile Roll Forming Machine For Tipo Teja Americana Normal Tile

Dapatkan Harga Terbaik

Video

Decking Flooring Board 1.2mm Floor Tile Making Machine

Dapatkan Harga Terbaik

Video

45 Steel Deck Roll Forming Machine Cold ±2mm Cutting Tolerance Excellent Performance

Dapatkan Harga Terbaik

Hubungi Kami

Hubungi Sekarang

Deskripsi produk

Hot Sale 915 Floor Deck Roll Forming Machine Full Automatic Hydraulic System

Hot Sale 915 Floor Deck Roll Forming Machine Full Automatic Hydraulic SystemWorking flow

Decoiler----feeding----roll forming----pressing----cut to length----output table

The metal deck produced by floor decking roll forming line has high strength with big wave length. It adheres well to concrete. Used on high building, it not only saves steel mold plate, but also reduces the weight of storey. With the same bearing capacity, it economized steel and cuts down investment accordingly. We can also supply the customized machines.

Applications of Deck Floor Roll Forming Machine:

The finished products are widely used in floor flat, after make embossing of the sheet, it will increase the strength between the steel and concrete, thereby increasing the floor of the fastness.

Specification

Suiting material	Galvanized coils
Forming speed	25m/min
Machine frame	H450
Roller Material	45# Steel, plated chrome
Forming rollers qty.	32 stations
Main motor	11kw*2
Feeding width or coil width	1220mm (Can be designed as per buyer's request)
Material Thickness	0.8-1.2mm
Applicable material	Galvanized coils(GI coils)
Yield strength of material	235Mpa-350Mpa

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
