Name: Steel Metal Rain Gutter Roll Forming Machine Automatic Control
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Mesin pembentuk gulungan talang
Price: 16,500.00 USD
Availability: InStock

Rumah > Produk > mesin roll forming pipa bawah >

Steel Metal Rain Gutter Roll Forming Machine Automatic Control

Steel Rain Gutter Roll Forming Machine

Metal Rain Gutter Roll Forming Machine

Automatic Control Rain Gutter Making Machine

Tempat asal:

CINA

Nama merek:

CANGZHOU FMS

Sertifikasi:

ISO CE

Nomor model:

Mesin pembentuk gulungan talang

Hubungi Kami

Minta Penawaran Harga

Detail Produk

Nama Produk:

Mesin Roll Forming Talang Air Logam Otomatis Atap Baja Talang Air Logam

Kecepatan:

15m/mnt

Cutting Blade Material:

Kr 12 Bergerak

Ketipisan bergulir:

0.3-0.8mm

Lebar makan:

330mm

Berat kotor per satuan produk:

2.5t

Voltase:

380V 50Hz 3fase atau sesuai kebutuhan Anda

Sistem Pengendalian:

PCL

Nilai jual utama:

Akurasi tinggi

Menyoroti:

Steel Rain Gutter Roll Forming Machine

Metal Rain Gutter Roll Forming Machine

Automatic Control Rain Gutter Making Machine

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Harga

negotiable

Kemasan rincian

FLC 20'

Waktu pengiriman

30 hari kerja

Syarat-syarat pembayaran

L/c, t/t, d/a, d/p

Menyediakan kemampuan

20 set per bulan

Produk terkait

Mobile Vegetable Planting Trough Forming Machine with Hydraulic Motor 5.5KW and 8-15m/min Production Capacity for Greenhouse Vegetable Cultivation

Dapatkan Harga Terbaik

Portable Gutter Roll Forming Machine with 500mm Feeding Width and 8-15m/min Production Capacity for Various Growing Methods

Dapatkan Harga Terbaik

Mobile Greenhouse Vegetable Planting Trough Forming Machine With Quickly And Efficiently 5.5KW Hydraulic Motor

Dapatkan Harga Terbaik

Portable Greenhouse Planting Trough Forming Machine with Hydraulic Motor 5.5KW 380V/50Hz/3Phase and 45# Steel Shaft

Dapatkan Harga Terbaik

Hubungi Kami

86-317-2016816

Hubungi Sekarang

Deskripsi produk

Steel Metal Rain Gutter Roll Forming Machine Automatic Control

Seamless rain gutter cold roll forming machine is composed of uncoiler, the feed leading table, the main machine, the formation cutting device, hydraulic system, control system and the product bracket.

Specification

Suitable material	PPGI GI AL
Thickness	0.3-0.5mm as per requested.
Power	380V 50Hz 3Phase as per requested.
Main motor	5.5KW
Hydraulic motor	4 KW
Speed	15m/min
Forming stations	12 rows
Roller material	Cr12 steel with vacuum heat treatment HRC57°-60°
Shaft material	45# steel quenched and tempered
Shaft diameter	50mm
Drive	Gear
Screem HMI	Delta , Touch Screen
PLC	Delta , Siemens
Processing precision	Within 1mm
Size	4.6m×1.5m×1.2m
Weight	2.5T

Installation

During the installation and adjustment of the device, our engineers should provide the buyer's personal request to provide training and maintenance of the equipment. Including basic buildings, electrical engineering, hydraulic oil, safety operations and non -standard safety items, test materials, etc.

Guarantee

The warranty will be maintained and during the delivery period during the delivery period. Due to the quality of the equipment during the guarantee period, we will provide parts for free, which is the correct operating condition.

Payment terms

30% in advance

70% is paid before shipping
