Name: Full Automated Drywall Roll Forming Machine CZ Channel 12m/Min
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: C Purlin
Price: 32,500.00 USD
Availability: InStock

Rumah > Produk > Mesin Pembentuk Gulungan CZ Purlin >

Full Automated Drywall Roll Forming Machine CZ Channel 12m/Min

Full Automated Drywall Roll Forming Machine

Automated CZ Purlin Roll Forming Machine

12m/min C And Z Purlin Machine

Tempat asal:

CINA

Nama merek:

FMS

Sertifikasi:

CE,ISO

Nomor model:

C Purlin

Hubungi Kami

Minta Penawaran Harga

Detail Produk

Nama Produk:

Mesin Roll Forming Drywall Otomatis Penuh Mesin Roll Forming Saluran CZ Purlin

Kapasitas Produksi:

8-12 m/mnt

Voltase:

380V/50HZ 3Phase (sesuai Permintaan Pelanggan)

Kekuatan (w):

15kw

Otomatisasi:

Otomatis

Cutting Blade Material:

Kr 12 Bergerak

Berat:

7,5T

Dimensi (P*L*T):

8m*1.1m*1.2m

Menyoroti:

Full Automated Drywall Roll Forming Machine

Automated CZ Purlin Roll Forming Machine

12m/min C And Z Purlin Machine

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Harga

negotiable

Kemasan rincian

Mesin utama telanjang, kotak kontrol komputer dikemas dengan plastik.

Waktu pengiriman

30 hari

Syarat-syarat pembayaran

T/T, Western Union, L/C

Menyediakan kemampuan

20 set per bulan

Produk terkait

Video

High Efficiency CZ Purlin Roll Forming Machine with 45# Steel Rollers and High Straightness for Construction

Dapatkan Harga Terbaik

Video

Full Automatic CZ Purlin Roll Forming Machine with High Straight Level Crush Resistance and 1.5-3MM Thickness for Industrial Buildings

Dapatkan Harga Terbaik

Video

CZ Purlin Roll Forming Machine with 18 Station Rollers, 380V/50HZ/3Phase Voltage and Cr12Mov Cutting Blade for High Efficiency

Dapatkan Harga Terbaik

Video

CZ Purlin Roll Forming Machine with 700014001500mm Size 8-12m/min Forming Speed and 1.5-3.0mm Thickness for Galvanized Steel

Dapatkan Harga Terbaik

Hubungi Kami

86-317-2016816

Hubungi Sekarang

Deskripsi produk

Full Automated Drywall Roll Forming Machine CZ Channel Purlin Roll Forming Machine

Changing C to Z:
1) Changing size: automatic,change sizes by press button.
2) Adjust the screw pole manually to adjust the distance between upper and lower rollers to form different thickness product
3) Quick change C to Z
Purlin in any size can be made without changing cutting molds. It’s different from traditional cutting device

It is suitable for industrial and civilian buildings, warehouses, special buildings, large -span steel structured roofs, wall surfaces, and internal and external wall decorations. It has light quality, high -strength, rich color, convenient construction, earthquake resistance, fire prevention, rainproof, life span The characteristics of long, exempt maintenance, have been widely promoted and applied to the color steel encirclement building system

specifications

Item Name	Specification
1	Effective width	80-300 mm
2	Thickness of feeding material	1-3 mm coil sheet
3	Roller station	8-12 stations
4	Shaft Diameter	80 mm
5	Productivity	8-12 m/min
6	Rollers' material	45# steel forge
7	Shaft material	45# steel
8	Weight	8tons
9	length	8 m
10	Voltage	380V 50Hz 3phases
11	Control	PLC
12	Decoiler	5 tons
13	Motor	11kw
14	Driving way	Chain transmission
15	Chain size	1-2 inch
16	Cutting system	Hydraulic cutte

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
