Color Stone Coated 0.32mm Roof Tile Production Line Servo Motor

0.32mm roof tile production line

servo motor roof tile production line

stone coated roof tile production line

Tempat asal:

China daratan

Nama merek:

CANGZHOU FMS

Sertifikasi:

ISO CE

Hubungi Kami

Minta Penawaran Harga

Detail Produk

Nama Produk:

Lini Produksi Genteng Dilapisi Batu Warna

Kapasitas Produksi:

6-10 buah/menit

Kekuatan:

113kw

Dimensi (P*L*T):

65*1.35*1.2m

bagian kedua:

mesin pemotong bentuk

bagian empat:

bagian penyemprotan lem bawah otomatis

Jaminan:

1 tahun

Ketebalan Pabrik Baja:

0,32-0,50mm

Menyoroti:

0.32mm roof tile production line

servo motor roof tile production line

stone coated roof tile production line

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Harga

negotiable

Kemasan rincian

FLC 40'

Waktu pengiriman

30 hari kerja

Syarat-syarat pembayaran

L/c, t/t, d/a, d/p

Menyediakan kemampuan

20 set per bulan

Produk terkait

6m Automatic Stacker for Roof Sheet Roll Forming Machine

Dapatkan Harga Terbaik

Video

the factory price for 0.3-0.8mm thickness Glazed Roof sheet forming machine

Dapatkan Harga Terbaik

Video

2025 New Design for Glazed Roof Tile Roof Sheet Roll Forming Machine With 18 Rows

Dapatkan Harga Terbaik

Video

4meter/Min Glazed Tile Roll Forming Machine With 18 Rows

Dapatkan Harga Terbaik

Hubungi Kami

86-317-2016816

Hubungi Sekarang

Deskripsi produk

Color Stone Coated Roof Tile Production Line

One benefit of stone coated metal roofing tiles is to protect your home from UV rays and keep it fresher in summer, which means that you spend less money on cooling your home.

The stone coated metal roofing tiles are main commonly used abroad because of their aesthetic look. Stone coated roofing tiles are made up of an Aluminium – zinc alloy coated with naturally mined granules. They come in a variety of profiles. Three common profiles are the shingle, classic and shake profiles.

Specification

Appearance size	400010002000mm
Driving section	3KW Excitation motor or frequency speed regulation (AS per customers’ requirements )
Automatic pressure spray tank	1 set ; Capability: 200kg ; Range: 0.6~1Mpa
Automatic glue machine motor	Servo motor ; Power: 750w ; PLC
Automatic spray gun	4 set (spare parts)
Dust collecting fan	1 set ; Power: 200w
Damp proof lamp	1 pc ; Power: 100w
Conveying device	Chain reciprocating
Air compressor	1 set ; Power: 7.5kw
Dust control of axial flow fan	1 set ; Power: 200w
Agitator	1 set ; Power: 1.5kw

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.
2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment
60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port
The Delivery Time: 30 days after the down payment is received.
