Name: Glazed Metal Tile Making PPGI Roof Roll Forming Machine Auto Cutting
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Bertemu Ubin / Ubin Mengkilap
Price: 28,000.00 USD
Availability: InStock

Rumah > Produk > Mesin Roll Forming Atap >

Glazed Metal Tile Making PPGI Roof Roll Forming Machine Auto Cutting

auto cutting roof roll forming machine

ppgi tile roof roll forming machine

ppgi roof tile roll forming machine

Tempat asal:

China daratan

Nama merek:

CANGZHOU FMS

Sertifikasi:

ISO CE

Nomor model:

Bertemu Ubin / Ubin Mengkilap

Hubungi Kami

Minta Penawaran Harga

Detail Produk

Nama Produk:

Mesin Pembuat Genteng Logam Mengkilap Atap Berkualitas Tinggi Pemotongan Otomatis

Berat:

8500 kg

Voltase:

380V 50HZ 3 Fase atau Lainnya

Cutting Blade Material:

Kr 12Mov

Jaminan:

1 tahun

Kapasitas Produksi:

15 m/mnt

Ketipisan bergulir:

0.3-0.8mm

Akurasi pemotongan:

±2 mm

Menyoroti:

auto cutting roof roll forming machine

ppgi tile roof roll forming machine

ppgi roof tile roll forming machine

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Harga

negotiable

Kemasan rincian

FLC 40'

Waktu pengiriman

35 hari kerja

Syarat-syarat pembayaran

L/c, t/t, d/a, d/p

Menyediakan kemampuan

20 set per bulan

Produk terkait

Video

Standard Corrugated Galvanized Sheets Machine Standard Corrugated Galvanized Sheets Line

Dapatkan Harga Terbaik

Video

Corrugated Sheet Machine Corrugated Roofing Tile Roll Forming Machine

Dapatkan Harga Terbaik

Video

Metal Roof Tile Trapezoidal Roll Forming Machine 5.5kw

Dapatkan Harga Terbaik

Video

High Material Quality C89 Light Gauge Steel Framing Building Roll Forming Machine

Dapatkan Harga Terbaik

Hubungi Kami

86-317-2016816

Hubungi Sekarang

Deskripsi produk

High Quality Roof Glazed Metal Tile Making Machinery Auto Cutting

Roofing colored steel tile, also known as: colored pressing tile, is the use of color coating steel plate, cold bending through the roll into a variety of wave plate.

Metal glazed tile is a new kind of building materials, the archaist sheet for roofing, like the wood one and clay one.The metal glazed tile roof sheet is more easy to install and using life time is more longer.With the market demand, the metal glazed tile roofing sheet is getting more popular.

Steel roof tiles are a new alternative to traditional clay concrete tiles. They are popular because of low cost and short construction period; they are recycled, beautiful in appearance, uniform in paint, high in strength and durable. They are widely used in industrial and civil buildings, such as factories, warehouses, garages, villas, luxury houses, hangars, sports halls, exhibition halls, theaters and other rooms and walls.

Specification

Key Selling Points	High Productivity
Rolling thinckness	0.3-0.8mm
Feeding width	1200mm
Machinery Test Report	Provided
Video outgoing-inspection	Provided
Marketing Type	New Product 2021
Warranty of core components	1 Year
Core Components	Pressure vessel, Motor, Other, Bearing, Gear, Pump, Gearbox, Engine, PLC
Raw material	PPGI PPGL GI GL
Cutting blade material	Cr 12Mov
Roller material	45#steel Chrome Plated
Shaft material	45# Steel Outer Diameter: 70mm
Control system	Siemens Control System

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
