Self Lock Standing Seam Roll Forming Machine For Color Steel Roofing Sheet

roofing standing seam roll forming machine

selflock standing seam roll forming machine

self lock standing seam roll former

Tempat asal:

CINA

Nama merek:

FMS

Sertifikasi:

CE,ISO

Hubungi Kami

Minta Penawaran Harga

Detail Produk

Nama Produk:

Mesin Roll Forming Jahitan Berdiri Self Lock Lembar Atap Baja Warna Tipe Ghana

Komponen inti:

Motor, Pompa, PLC

Voltase:

380V atau sesuai kebutuhan

Panggung Rol:

16 stasiun roller

Ketebalan kerja:

0,3-0,7mm

Bahan roller:

45 # baja Berlapis Krom

Berat:

1800 kg

Lebar makan:

400mm

Menyoroti:

roofing standing seam roll forming machine

selflock standing seam roll forming machine

self lock standing seam roll former

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Harga

negotiable

Kemasan rincian

Mesin utama telanjang, kotak kontrol komputer dikemas dengan plastik.

Waktu pengiriman

30 hari

Syarat-syarat pembayaran

T/T, Western Union

Menyediakan kemampuan

30 set per bulan

Produk terkait

Video

Standard Corrugated Galvanized Sheets Machine Standard Corrugated Galvanized Sheets Line

Dapatkan Harga Terbaik

Video

Corrugated Sheet Machine Corrugated Roofing Tile Roll Forming Machine

Dapatkan Harga Terbaik

Video

Metal Roof Tile Trapezoidal Roll Forming Machine 5.5kw

Dapatkan Harga Terbaik

Video

High Material Quality C89 Light Gauge Steel Framing Building Roll Forming Machine

Dapatkan Harga Terbaik

Hubungi Kami

86-317-2016816

Hubungi Sekarang

Deskripsi produk

Self Lock Standing Seam Roll Forming Machine Ghana Type Color Steel Roofing Sheet

The ability to remove and replace a single metal roofing panel without having to take off the entire roof is an amazing advantage and something that other standing seam metals profiles can not do. Because life happens, things change, and homes and buildings need to meet the needs of different people or building occupants over time mean additions and remodels happen. Changes or repairs on chimneys, skylights, HVAC units, or even fixing storm damage is all a realty.

Equipment Detailed Parameters

Metal material thickness	0.3 - 0.8mm
Metal material width	400mm or as client require
Roller Stage	16 rows
Roller Material	45# forging steel with chromium plate
Diameter of shaft	Φ70mm
Material of cutting blade	Cr12Mov, Quenched treatment 58℃-60℃
Main Structure of the Machine	300H beams
Side Panel of Machine	16mm
Chain	1 inch
Motor power	5.5kw
Hydraulic pump power	4 kw
Productivity	8-12 meters per minute

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
