Name: Circular Arc Steel PPGI 0.3mm Roof Tile Roll Forming Machine
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Busur Lingkaran
Price: 16,000.00 USD
Availability: InStock

Rumah > Produk > Mesin Roll Forming Genteng >

Circular Arc Steel PPGI 0.3mm Roof Tile Roll Forming Machine

PPGI tile forming machine

PPGI roof tile roll forming machine

0.3mm roof tile roll forming machine

Tempat asal:

China daratan

Nama merek:

CANGZHOU WILLING

Sertifikasi:

ISO CE

Nomor model:

Busur Lingkaran

Hubungi Kami

Minta Penawaran Harga

Detail Produk

Nama Produk:

Mesin Roll Forming Genteng Baja Busur Melingkar

Layanan purna jual disediakan:

Insinyur tersedia untuk mesin layanan di luar negeri, dukungan teknis video, dukungan online, layana

Bahan mentah:

Lembaran PPGI/Galvanis

Voltase:

380/50Hz/3PH

Sistem Pengendalian:

PLC

Berat:

2.2t

Kapasitas Produksi:

10-15m/mnt

Ketebalan:

0.3mm-0.8mm

Kekuatan:

5.5kw

LEBAR BAHAN BAKU:

1000mm

Menyoroti:

PPGI tile forming machine

PPGI roof tile roll forming machine

0.3mm roof tile roll forming machine

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Harga

negotiable

Kemasan rincian

FLC 40'

Waktu pengiriman

30 hari kerja

Syarat-syarat pembayaran

L/c, t/t, d/a, d/p

Menyediakan kemampuan

20 set per bulan

Produk terkait

6m Automatic Stacker for Roof Sheet Roll Forming Machine

Dapatkan Harga Terbaik

Video

the factory price for 0.3-0.8mm thickness Glazed Roof sheet forming machine

Dapatkan Harga Terbaik

Video

2025 New Design for Glazed Roof Tile Roof Sheet Roll Forming Machine With 18 Rows

Dapatkan Harga Terbaik

Video

4meter/Min Glazed Tile Roll Forming Machine With 18 Rows

Dapatkan Harga Terbaik

Hubungi Kami

Hubungi Sekarang

Deskripsi produk

Circular Arc Steel Tile Roof Tile Roll Forming Machine

With more than 10 years work experience, our Circular Arc Steel Tile Roof Tile Roll Forming Machine has been exported to many countries.
Due to its durability, convenient operation, stable operation, good material, high hardness, and long operating life, the tile press is highly praised by a wide range of users.

Specification

No.	Item	Description
1	Coil	Galvalume, Galvanized, PPGI, Aluminum
2	Raw Material Thickness	0.3-0.8mm
3	Working Speed	10-15m/min ( not including the cutting time)
4	Roller Station	16 Raws
5	Dimension (LWH)	7500 mm1500 mm1500 mm
6	Machine Weight	5500 KG
7	Electrical Control System	Panasonic PLC (can be customized)
8	Drive Motor Power	5 KW
9	Hydraulic Station Power	5 KW
10	Power Supply	380V/60HZ/3 PH
11	Cutting Accuracy	±2 mm
12	Driving Mode	Single Chain 1 inch
13	Material of Shaft	70 mm 45#steel forged
14	Material of Roller	45# Steel Finish Machining, Plated Hard

Application

Arc steel plates are mainly used for roofs, walls, doors, large-span factories, warehouses, office buildings, villas, roof additions, air purification rooms, cold storage, shops, kiosks and temporary houses in industrial and commercial buildings.

Advantage

(1) Manual uncoiler
It is used to support the steel coil and realize the uncoiling by means of rotatory movement. The steel coil is uncoiled manually. The capacity of this uncoiler is 5 Ton.
(2) Feeding table
Receiving the raw material (steel sheet), it guarantees parallel and everything is uniformity.
(3) Machine material
welded steel frame structure of our machine, AC frequency conversion motor reducer drive, chain transmission, heat treatment works together In order to get high quality product
(4) Shearing system
It adopts hydraulic station and automatic cut to length system to realize the stably cutting of certain length of products.
(5) Hydraulic system
The system includes a set of hydraulic tank, a set of a Gear Pump, two hydraulic pipes .and two sets of Solenoid Valves works together to make sure the cuting is stability.

Circular Arc Steel PPGI 0.3mm Roof Tile Roll Forming Machine 0
