Name: Liner And Profile Double Layer Roll Forming Machine 415V 1220/1450mm Width
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: 1450
Price: 28,000.00 USD
Availability: InStock

Rumah > Produk > Mesin Roll Forming Atap >

Liner And Profile Double Layer Roll Forming Machine 415V 1220/1450mm Width

metal roof panel machine

roofing sheet roll forming machine

Tempat asal:

CINA

Nama merek:

cangzhou willing

Sertifikasi:

CE,ISO

Nomor model:

1450

Hubungi Kami

Minta Penawaran Harga

Detail Produk

Bahan mentah:

Lembaran PPGI/Galvanis

Ketebalan:

0.3-0.8mm

Nama Produk:

415V Liner Dan Profil 2 Lapisan Atap Mesin Roll Forming Lebar 1220/1450mm

Pembentukan kecepatan:

8-15m/mnt

Lebar bahan:

1450mm

Layanan purna jual disediakan:

Insinyur tersedia untuk melayani mesin di luar negeri

Menyoroti:

metal roof panel machine

roofing sheet roll forming machine

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 Set

Kemasan rincian

Mesin utama telanjang, kotak kontrol komputer dikemas dengan plastik.

Waktu pengiriman

30 hari

Syarat-syarat pembayaran

T/T, Western Union

Menyediakan kemampuan

30 set per bulan

Produk terkait

Video

Standard Corrugated Galvanized Sheets Machine Standard Corrugated Galvanized Sheets Line

Dapatkan Harga Terbaik

Video

Corrugated Sheet Machine Corrugated Roofing Tile Roll Forming Machine

Dapatkan Harga Terbaik

Video

Metal Roof Tile Trapezoidal Roll Forming Machine 5.5kw

Dapatkan Harga Terbaik

Video

High Material Quality C89 Light Gauge Steel Framing Building Roll Forming Machine

Dapatkan Harga Terbaik

Hubungi Kami

86-317-2016816

Hubungi Sekarang

Deskripsi produk

415V Liner And Profile 2 Layers Roof Roll Forming Machine 1220/1450mm Width

One machine can produde two different shapes.

Save spave

Save money

Equipment Detailed Parameters:

No.	Item	Description
1	Coil	Width:1220mm & 1450mm
2	Forming speed	8-15 m/min (not including cutting time)
3	Roller Stations	9 stations & 22 stations
4	Material of Roller	45# steel finish machining, plated hard chromium surface
5	Material of Main Shaft	45# steel finishing machining and then slack quench processed
6	Material of Shaft	70 mm 45#steel forged
7	Driven Motor Power	5.5 KW
8	Hydraulic Station Power	4 KW
9	Hydraulic Station Pressure	12.0 Mpa
10	Electrical Control System	Panasonic PLC
11	Dimension (LWH)	11000mm1500mm1500mm
12	Material of Cutter	GCr12
13	Driving Mode	single chain 1 inch
14	Material Thickness	0.3-0.8mm
15	Power Supply	415V, 50HZ, 3 PHASES
16	Cutting accuracy	±2 mm

Liner And Profile Double Layer Roll Forming Machine 415V 1220/1450mm Width 0

Liner And Profile Double Layer Roll Forming Machine 415V 1220/1450mm Width 1
